Skylark Network is a leading provider of advanced solar energy storage solutions. We specialize in 48V 200Ah, 400Ah, and 500Ah LiFePO4 lithium battery packs for solar systems. Our products are designed to offer high efficiency and long-lasting performance. Inquire today to learn more!
Parameter | Value |
Model | GBP48V-50AH, GBP48V-100AH, GBP48V-200AH, GBP48V-500AH, GBP48V-1000AH |
Nominal Voltage (V) | 48 |
Nominal Capacity (AH) | 50, 100, 200, 500, 1000 |
Working Voltage Range (V) | 42-56.25 |
Recommended Charging Voltage (V) | 52.5 |
Recommended Discharging Cutoff Voltage (V) | 45 |
Standard Charging Current (A) | 25, 50, 100, 100, 200 |
Max. Constant Charging Current (A) | 50, 100, 200, 500, 1000 |
Standard Discharging Current (A) | 25, 50, 100, 100, 200 |
Max. Discharging Current (A) | 50, 100, 200, 500, 1000 |
Temperature Range (℃) | -30℃～60℃ (Recommend 10℃～35℃) |
Allowable Humidity Range | 0～85% RH |
Storage Temperature Range (℃) | -20℃～65℃ (Recommend 10℃～35℃) |
Protection Level | IP20 |
Cooling Method | Natural air cooling |
Maximum Dimension (WDH) for Rack Type | 483360175, 483535175, 750780350, 5504831755, 55048317510 |
Net Weight | 30KG, 56KG, 114KG, 280KG, 560KG |
Battery Cell | A Grade Prismatic Cell |
Protection | Built-in Smart BMS |
The 48V 200Ah 400Ah 500Ah LiFePO4 Lithium Battery Pack is designed for solar systems. This battery offers various capacities ranging from 50Ah to 1000Ah, making it suitable for different energy storage needs.
The nominal voltage is 48V, with a working voltage range of 42-56.25V. The recommended charging voltage is 52.5V, ensuring safe and efficient charging.
The standard charging current varies by model, with options from 25A to 200A. The maximum constant charging current can reach up to 1000A for larger models.
For discharging, the battery supports standard currents from 25A to 200A. The maximum discharging current also reaches 1000A for the highest capacity models.
The operating temperature range is from -30°C to 60°C, with an optimal range of 10°C to 35°C. The storage temperature range is -20°C to 65°C, ideal for various climates.
The battery is IP20 rated for protection and uses natural air cooling. It is built with A-grade prismatic cells and a smart Battery Management System (BMS) for enhanced safety.
Dimensions vary by model, with the largest model measuring 750x780x350mm. The weight ranges from 30kg to 560kg depending on capacity.
Skylark Network's LiFePO4 battery packs are perfect for residential and commercial solar systems, offering long-lasting performance and reliable power storage.
High Energy Efficiency: The advanced LiFePO4 technology offers high energy density and long lifespan. It outperforms traditional lead-acid batteries in both efficiency and durability.
Customizable Capacity: Available in 200Ah, 400Ah, and 500Ah options, this battery pack can be tailored to meet varying user energy storage needs. It is versatile for different system sizes.
High Safety Standards: Equipped with a built-in smart Battery Management System (BMS), the battery ensures protection against overcharging, over-discharging, overheating, and short circuits. This enhances safety and reliability.
Durability and Reliability: The battery can endure over 4000 charge and discharge cycles, offering stable performance over time. It is designed for long-term use in demanding conditions.
Environmentally Friendly: Made from non-toxic, recyclable materials, the battery supports sustainable energy solutions, contributing to a cleaner environment and reducing waste.
Wide Application: Ideal for solar systems and uninterruptible power supplies (UPS), this battery is perfect for both residential and commercial use. It ensures stable and efficient power storage.
Compact and Durable Design: Measuring 552x400x400mm and weighing 91kg, this battery is compact and easy to install and transport. Its robust construction guarantees long-lasting performance.
Customization Services: Skylark Network offers OEM/ODM services to cater to specific customer requirements. The battery pack can be adjusted for various applications and needs.
Long Warranty: The battery comes with a 10-year warranty, offering peace of mind for users. It supports off-grid or hybrid grid systems for flexible energy solutions.
Delivery Time: Delivery time is typically 15 days for orders up to 50,000 units. Larger orders may take longer.
Shipping Method: We offer sea and air freight options. Shipping methods are chosen based on order quantity and destination.
Customization Options: OEM/ODM services are available. Customization includes battery capacity, logos, and packaging.
Warranty: The battery pack comes with a 10-year warranty, ensuring reliable performance over its lifespan.
After-Sales Service: Skylark Network provides comprehensive after-sales support, including maintenance services in multiple countries.
Promotional Support: Skylark Network offers marketing materials and product details to assist with promotion efforts for resellers.
Residential and commercial solar systems
Off-grid and backup power solutions
Renewable energy storage systems
